Schiit Audio Modius

BEFORE YOU ADD TO CART

All Schiit Audio products come with 230V / UK plug by default.

Select "Buy Now Pay Later" payment method for Schiit Audio products will incur additional transaction fee. We sincerely apologise for the inconvenience and appreciate your understanding.

Chat with us on promotions and shipping discounts

Sale price$469.00 SGD

Tax included. Shipping calculated at checkout.

Finish: Black

Modius? Yes, as in “Modius Maximus,” a bigger, balanced-output Modi with super-high performance—and even better versatility. Connect to any computer or streamer—or tablet, TV, CD player, or many other sources—and Modius delivers exceptional sound.

High Performance DAC and USB

Modius E features Schiit’s exclusive Unison USB™ interface, which provides plug-and-play compatibility with virtually any modern device. Combined with the ESS ES9028 D/A converter and dedicated balanced and single-ended output stages with DC-coupled output, Modius provides exceptional performance for a very low price.

Class-Leading Versatility

Plug Modius E into virtually any computer or streamer with the included USB A-C cable and you’re ready to go. Or, choose optical, coaxial, or AES digital sources and use the included wall power supply. Or, if you want to connect your phone or tablet—something that needs very low power draw—again, use the included wall power supply to eliminate dreaded “draws too much power” errors. That’s right—Modius accepts pretty much any input you can throw at it!

Perfect Stack with Asgard, Jotunheim, and Lyr

Modius E  has exactly the same footprint as our popular mid-sized amp series. If you’re looking for more connectivity than the internal cards provide, Modius is a perfect pair. Don’t have one of our amps? No worries, Modius works great with virtually anything!

Schiit Audio Modius
Schiit Audio Modius Sale priceFrom $469.00 SGD
Specifications

SE or Balanced Outputs:

  • Frequency Response: 20Hz-20KHz, +/-0.02dB
  • THD+N: 0.0003%, with or without external power
  • IMD: 0.0004%, CCIR, with or without external power
  • S/N: > 118dB, referenced to full output, with or without external power
  • Crosstalk: -125dB, 20-20kHz

Maximum Output:4.0V RMS balanced, 2.0V RMS single-ended

Inputs:USB, Toslink SPDIF, Coaxial SPDIF, AES

Sample Rates and Bit Depths:16/44.1 to 24/192

USB Input Receiver: Schiit Unison USB™

D/A Conversion IC:ESS ES9028

Analog Stage:Based on LME49724 for balanced output, OPA1656 for SE output, both independent, with precision thin-film resistors and film capacitors, DC coupled

Output:XLR balanced and RCA single-ended

Output Impedance:75 ohms

Power Supply:USB powered with +/-5V switching rail generator; auxiliary USB power input for 0mA USB power draw devices (like phones and tablets)

Size:9 x 6 x 1.5”

Weight:2 lb

APx555 Report for Modius E

Warranty
  • Authorised Distributor Warranty - 1 Year
  • Conditional Freight Cost Applies
